Professional Stereoscopic Motion Video

TriD Stereoscopic Video Recording System

NEOTEK proudly announces the release of our next generation video product, TriD, which replaces the TriDVD DVD-based system with much greater capability and flexibility. Now, you can have the image quality of our educational system with easy to use smooth motion capability and a wide selection of the best available cameras.

We will of course continue to support the older system and will offer a substantial discount upgrade to our newer system for current TriDVD users.

Features

Maximum resolution of 1280x1024 pixels per eye for stunning detail

Frame rates of up to 60 fps for very smooth motion

Fully digital for "Picture Perfect Pauses"

Up to 500% more image pixels than analog systems

Wide range of commercial cameras are compatible

Wide range of storage and distribution media including DVD, CD, RAID, LAN

Projection system compatible (CRT, DLP)

Windows XP compatible

Simple VCR-like interface

Specifications

Resolutions Supported	1280x1024 1024x768 720x486 640x480
Framerates (FPS)	7.5 fps (SXGA) 15 fps (XGS) 24 fps 30 fps 60 fps(interlaced)
Bitrates	50 MB/s Uncompressed XGA 35 MB/s Uncompressed DV 3 Mb/s Compressed XGA 5 Mb/s Compressed DV
Media	RAID-1 (Uncompressed Recording) DV Tape (Compressed Recording) Twin DVD (+R,+W) (Compressed Recording) CDR (Commpressed Recording, 30 min. max) LAN (10bT or faster) Transfers
Camera Interfaces	DV IEEE 1394 (Firewire)
Display Interfaces	Synch-Doubled 120 Hz Liquid Crystal Shutter Glasses

Pricing

TriD Kit TriD Turnkey Retro-Opsis DV Turnkey

Price $4,700 $9,850 $25,000

Hardware TriD DVD
NEOTEK Video Processor
2 Pair Liquid Crystal Glasses TriD Kit+
2.2GHz Pentium PC w/
240GB RAID System
21" Sony Monitor
Dual Camera Ready Inputs TriD Turnkey+
1TB RAID System
2 Sony High Res Cameras
Dual C-Mount Couplers

Minimum
Specification 2.2 GHz PC
Windows XP
64MB Video Card
Two IEEE 1394 Cards
120GB Fast Disk
DVD Burner
2 Firewire or DV Cameras 2 Firewire or DV Cameras Zeiss or Leica Microscope

	TriD Kit	TriD Turnkey	Retro-Opsis DV Turnkey
Price	$4,700	$9,850	$25,000
Hardware	TriD DVD NEOTEK Video Processor 2 Pair Liquid Crystal Glasses	TriD Kit+ 2.2GHz Pentium PC w/ 240GB RAID System 21" Sony Monitor Dual Camera Ready Inputs	TriD Turnkey+ 1TB RAID System 2 Sony High Res Cameras Dual C-Mount Couplers
Minimum Specification	2.2 GHz PC Windows XP 64MB Video Card Two IEEE 1394 Cards 120GB Fast Disk DVD Burner 2 Firewire or DV Cameras	2 Firewire or DV Cameras	Zeiss or Leica Microscope
